19 kW to 1196 kW: Highly reliable, versatile & compact scroll or reciprocating compressor chillers that present relatively low installation & operating costs. The range incorporates Water Cooled & Air Cooled chiller models including a Free Cooling version. With low vibrations & associated noise levels, these chillers are equally suited to industrial process & commercial HVAC comfort cooling applications.
V Range offers two lines across all models each running different classes of refrigerant to accommodate customer priorities in terms of efficiency & environmental sustainability:-
![refrigeranti-V Standard & Low GWP Refrigerants V Range](https://www.turnbull-scott.co.uk/wp-content/uploads/2022/03/refrigeranti-V.png)
ENERGYMISER - Optimised for efficiency using R410a, a well used & understood refrigerant in both industrial & commercial applications, & now also low GWP (Global Warming Potential) refrigerant R452b.
GREENMISER - With eco-sustainability at the heart of design at Geoclima, this line, with reciprocating compressors, is optimised for very low GWP refrigerants HFO-1234ze & R290.
![v range Chiller V Range Scroll Compressor](https://www.turnbull-scott.co.uk/wp-content/uploads/2022/03/v.png)
Characterised by their compact size & light weight, these are particularly suited to smaller plants. However with the Energymiser line, larger capacities of several 000's kW can be achieved with Geoclima's innovative multi scroll compressor designs.
![v range Chiller V Range Scroll Compressor](https://www.turnbull-scott.co.uk/wp-content/uploads/2022/03/v.png)
V Range chillers are typically Energy Class A rated (unless specified for custom applications) under EU Ecodesign Energy-Related Products & Energy Information Regulations 2021 with impressive EERs.
![v range Chiller V Range Scroll Compressor](https://www.turnbull-scott.co.uk/wp-content/uploads/2022/03/v.png)
All units supplied completely wired & connection ready & equipped with proprietary, panel mounted Geotouch™ touchscreen programming & monitoring system. With strong metal structures each unit is painted with epoxy powder & anti-rust coating as standard.
Smart Chiller Technologies
![circlemod Circlemod modular industrial chillers](https://www.turnbull-scott.co.uk/wp-content/uploads/2022/03/circlemod-pic-300x300.jpg)
The novel modular Circlemod series (VHA CM) facilitates future-proofing of cooling capacity . Each module, at up to 150kW, can be added to over time to meet an increasing cooling load demand up to 1200kW. The unique cylindrical microchannel condensers provide a 45% increase in heat exchange surface over traditional designs lowering both air inflow & condensing temperatures. A conic air-intake flow optimiser increases condenser efficiency by 10%.
![Chiller Dynamic Noise Control Industrial Chiller Dynamic Noise Control](https://www.turnbull-scott.co.uk/wp-content/uploads/2022/03/dnc.jpg)
For environments sensitive to noise, the smart Dynamic Noise Control (DNC) system constantly measures chiller noise & "adapts" performance within permissible ranges & programmable time-slots.
![v range Chiller V Range Scroll Compressor](https://www.turnbull-scott.co.uk/wp-content/uploads/2022/03/v.png)
The V Range provides significant scope for customisation enabling precise configuration of each model optimising for specific applications, operating conditions & priorities. Options include custom dimensions, galvanised frames with hersite coils, low speed fans & compressor sound insulation kits - Low noise (LN) or super low noise (LLN), low temp chilled water/glycol to -3°C, extreme climate operation adaptions (-40°C & +40°C), pump pressurisation units & expansion vessels, construction for explosive environments.
Click here to contact our Technical Sales Team.
![vha-2 V Range Chiller](https://www.turnbull-scott.co.uk/wp-content/uploads/bb-plugin/cache/vha-2-landscape-e6a2a76d444672359b9b11185d39d2e1-60isaf3zrwtk.jpg)
VHA: 19kW - 1196kW
Air cooled chillers - scroll compressors (R452b) or reciprocating (R290 or HFO-1234ze) - Dry expansion evaporator - EC axial fans
![circlemod Circlemod modular industrial chillers](https://www.turnbull-scott.co.uk/wp-content/uploads/bb-plugin/cache/circlemod-pic-landscape-b274c1cc88154edf04805d676f885ef5-beqipzaw30un.jpg)
VHA CM: ≤150kW per module
≤8 modules (≤1200kW) - Air cooled chillers - scroll compressors - brazed plate exchanger evaporators - cylindrical condensers - EC axial fans
![V Range Chiller V Range Chiller](https://www.turnbull-scott.co.uk/wp-content/uploads/bb-plugin/cache/vha-fc-landscape-10d7d9e0f9ecc21fb2b6d1e09ff9daa6-cnk421d8h3bz.jpg)
VHA FC: 18kW - 1163kW
Air cooled chillers - Free Cooling system - scroll compressors (R452b) or reciprocating (R290, HFO-1234ze) - Dry expansion evaporator - EC axial fans
![Vhh Chiller V Range Water Chiller](https://www.turnbull-scott.co.uk/wp-content/uploads/bb-plugin/cache/vhh-2-landscape-7d12668d551cbbdec383e10ef514b377-2udt0v9am71i.jpg)
VHH: 19kW - 676kW
Water cooled chillers - indoor install - scroll compressors (R452b) or reciprocating compressors (R290 or HFO-1234ze) - Dry expansion evaporator
![VSE Chiller V Range Industrial Chiller](https://www.turnbull-scott.co.uk/wp-content/uploads/bb-plugin/cache/vse-1-landscape-cceae2fbdae05d2f90f48e8612661ab9-md1cykv073qg.jpg)
VSE: 19kW - 611kW
Condenserless unit for indoor install & connection to remote condenser (RCE) - scroll compressors (R452b) or reciprocating (R290 or HFO-1234ze) - Dry expansion evaporator
![V range (vsa) V Range Chiller Unit](https://www.turnbull-scott.co.uk/wp-content/uploads/bb-plugin/cache/vsa-landscape-7d438be514bb4fcfbd4aa705f3e21306-8l57h1ij6cgn.jpg)
VSA: 19kW - 1196kW
Condensing unit for outdoor install & connection to independ. evaporator - scroll compressors (R452b) or reciprocating (R290 or HFO-1234ze) - AC or EC axial fans
